AC Antennas 4G Multiband Cellular Antenna

AC Antennas

  • S$160.00

Contact Us Only 2 left!

Product Description

4GMultiband is an omnidirectional multiband antenna covering the cellular phone network bands simultaneously with data transmission, thus improving the communication performance for e.g. 3G, 4G, CDMA, UMTS, DECT, WLAN, GSM850/900/1800/1900, Bluetooth and EDGE. The 4GMultiband antenna is manufactured in premium quality materials in order to prevent galvanic corrosion. Radiating elements are made of copper.

The 4GMultiband antenna is subject for improvement at all times. The antenna has the same rugged design as all other AC Antennas products thus it withstands harsh environmental conditions, both on sea and land.

Note: N240F Mounting is included with this product.

Electrical Specifications

Part No. 400006-T
Product Name 4G Multiband
Frequency Range (MHz) 806-960 / 1.710-2.690
Power Rating (Watt) 40


Mechanical Specifications

Length (m/ft.) 0.44m / 1.40ft
Weight (kg/lbs.) 0.28kg / 0.62lbs
Thread 1" 14TPI, 1 1/4" 11TPI N-female
Parts included N240F with 1 1/4" thread included.


Further information
Product Sheet
Green Passport and Content Declaration

Product Code
ACM-4G MULTIBAND

Warranty Terms
Warranty period: 1 year from date of purchase
Terms and conditions apply
